D05 Pressure Reducing Valve

Model No.
MGV-03
Supplier
SEVEN OCEAN HYDRAULIC INDUSTRIAL CO., LTD.More About This Product
Request for Quotation

Seven Ocean D05 Pressure Reducing Valve

Spec

  • Type : Single stage
  • Function : Reduce Pressure on Port P, Reduce Pressure on Port A, Reduce Pressure on Port B
  • Pressure Adjusting Range : 2.5-35 Bar, 7-70 Bar, 7-140 Bar, 7-210 Bar

Key Features

Seven Ocean's D05 modular hydraulic pressure reducing valves are used to regulate pressure, in one area of a circuit, below normal system pressure, adjustable with a hand knob.  They are rated 21.1 GPM flow and 4570 PSI working pressure, 36-3045 PSI pressure adjustment range at pressure port, A port, or B Port.

Even when pressure changes in the primary circuit, the reduced secondary pressure is maintained at a constant level. This valve is well suited to perform pressure reducing function as it mounts directly below the directional control valve.


Seven Ocean Hydraulics Sandwich Valves
Explore Seven Ocean Hydraulics

D05 Pressure Reducing ValveSeven Ocean Hydraulics Sandwich Valve- MGV Pressure Reducing Valve



Schematics

Features:
  • Sandwich Plate Style Design
  • Direct Operated Pressure Reducing Valve
  • Four Pressure Adjusting Ranges are available
  • Pressure Reduction in Ports A, B, or P
  • Pressure Adjusting Options are available with handle knob or slotted screw
Technical Specifications
  • Nominal Size: NG10, CETOP-5, NFPA-D05 (ISO-4401-05)
  • Maximum Operating Pressure: 4570 PSI
  • Maximum Flow Rate: 21.1 GPM
  • Pressure Adjusting Range: 2.5-35 Bar, 7-70 Bar, 7-140 Bar, 7-210 Bar
  • Configuration: Reduced pressure on Port P; Reduced pressure on Port A; Reduced pressure on Port B
  • Weight: P, A, B Type: 8.4 lbs
Ordering Information:
  1. Sandwich Plate Design (Modular)
  2. Pressure Reducing Valve
  3. Nominal Valve Size: NG10, CETOP-05, NFPA-D05
  4. Configuration:
    • P: Reduced pressure on Port P
    • A: Reduced pressure on Port A
    • B: Reduced pressure on Port B
  5. Pressure Adjusting Range:
    • 0: 2.5-35 Bar
    • 1: 7-70 Bar
    • 2: 7-140 Bar
    • 3: 7-210 Bar
  6. Design Number/ Pressure Adjusting Options:
    • 10: With handle knob
    • 20: without handle knob, hexagon screw with lock nut
  7. Optional Specifications:
    • B: Handle knob at Port A side


Applications:Application and Industry

ˇ

Payment Details for Offline Orders

  • Payment Terms : TT ,L/C
  • Minimum Order : 1 Piece(s)

Last Update : 2020-07-01
